D.1 In-panel Wiring
D-5
D
 217IF Cable Connections
CN1, CN2, and RS-232C Cables
This section describes RS-232C transmission line connections for 217IF Module of the
MP920.
Table D.1 217IF RS-232C Transmission Line Connections
MP920 217IF
(CN1, CN2)
Cable Connections and
Signal Directions
Remote Station
(D-sub 25-pin)
Signal
Name
Pin No. Pin No. Signal
Name
FG
11
FG
SD(TXD)
22
SD(TXD)
RD(RXD)
33
RD(RXD)
RS
44
RS
CS(CTS)
55
CS(CTS)
DSR(DR)
66
DSR(DR)
SG
77
SG
DTR(ER)
920
DTR(ER)
MP920 217IF
(CN1, CN2)
Cable Connections and
Signal Directions
Remote Station
(D-sub 9-pin)
Signal
Name
Pin No. Pin No. Signal
Name
FG
11
FG
SD(TXD)
22
SD(TXD)
RD(RXD)
33
RD(RXD)
RS
44
RS
CS(CTS)
55
CS(CTS)
DSR(DR)
66
DSR(RD)
SG
77
SG
N.C.
88
N.C.
DTR(ER)
99
DTR(ER)
