3.7 Main Circuit Wiring
YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual 55
Electrical Installation
3
n Three-Phase 200 V Class
Table 3.3 Wire Gauge and Torque Specifications (Three-Phase 200 V Class)
Model
CIMR-T
Terminal
Recommended Gauge
mm
2
Applicable
Gauge
mm
2
Screw
Size
Tightening
Torque
Nxm (lb.in.)
2A0004
2A0006
2A0010
R/L1, S/L2, T/L3 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 2.5 2.5 to 6
–, +1, +2 – 2.5 to 6
B1, B2 – 2.5 to 6
2.5
<1> 2.5 to 6
2A0012
R/L1, S/L2, T/L3 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 2.5 2.5 to 6
–, +1, +2 – 2.5 to 6
B1, B2 – 2.5 to 6
2.5
<1> 2.5 to 6
2A0021
R/L1, S/L2, T/L3 4 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 2.5 2.5 to 6
–, +1, +2 – 4 to 6
B1, B2 – 2.5 to 6
4
<1> 4 to 6
2A0030
R/L1, S/L2, T/L3 6 4 to 16
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 6 4 to 16
–, +1, +2 – 6 to 16
B1, B2 – 4 to 6
6
<1> 6 to 10 M5
2 to 2.5
(17.7 to 22.1)
2A0040
R/L1, S/L2, T/L3 10 6 to 16
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 10 6 to 16
–, +1, +2 – 16
B1, B2 – 4 to 6
10 6 to 10 M5
2 to 2.5
(17.7 to 22.1)
2A0056
R/L1, S/L2, T/L3 16 16 to 25
M6
4 to 6
(35.4 to 53.1)
U/T1, V/T2, W/T3 16 16 to 25
–, +1, +2 – 16 to 25
B1, B2 – 6 to 10 M5
2 to 2.5
(17.7 to 22.1)
16 10 to 16 M6
4 to 6
(35.4 to 53.1)
2A0069
R/L1, S/L2, T/L3 25 16 to 25
M8
9 to11
(79.7 to 97.4)
U/T1, V/T2, W/T3 16 16 to 25
–, +1, +2 – 25
B1, B2 – 10 to 16 M5
2 to 2.5
(17.7 to 22.1)
16 16 to 25 M6
4 to 6
(35.4 to 53.1)
2A0081
R/L1, S/L2, T/L3 35 25 to 35
M8
9 to11
(79.7 to 97.4)
U/T1, V/T2, W/T3 25 25 to 35
–, +1, +2 – 25 to 35
B1, B2 – 16 M5
2 to 2.5
(17.7 to 22.1)
16 16 to 25 M6
4 to 6
(35.4 to 53.1)
2A0110
R/L1, S/L2, T/L3 35 25 to 50
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 35 25 to 50
–, +1 – 35 to 50
B1, B2 – 16 to 50
16 16 to 25
2A0138
R/L1, S/L2, T/L3 50 35 to 70
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 50 35 to 70
–, +1 – 50 to 70
B1, B2 – 25 to 70
25 25 M8
9 to 11
(79.7 to 97.4)
