3.7 Main Circuit Wiring
56 YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual
Note: Refer to the related instruction manuals for the applicable wire gauges when connecting peripheral devices to terminals -, +1, +3,
B1, and B2. Contact your Yaskawa representative or the nearest Yaskawa sales office directly for consultation if using a wire
gauge not listed in the manual.
n Three-Phase 400 V Class
Table 3.4 Wire Gauge and Torque Specifications (Three-Phase 400 V Class)
2A0169
R/L1, S/L2, T/L3 70 50 to 95
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 70 50 to 95
–, +1 35 to 95
+3 50 to 95
35 25 to 35
2A0211
R/L1, S/L2, T/L3 95 70 to 95
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 95 70 to 95
–, +1 35 to 95
+3 50 to 95
50 25 to 50
2A0250
R/L1, S/L2, T/L3 95 × 2P 95 to 150
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 95 × 2P 95 to 150
–, +1 70 to 150
+3 35 to 150 M10
18 to 23
(159 to 204)
95 95 to 150 M12
32 to 40
(283 to 354)
2A0312
R/L1, S/L2, T/L3 95 × 2P 95 to 150
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 95 × 2P 95 to 150
–, +1 70 to 150
+3 70 to 150 M10
18 to 23
(159 to 204)
95 95 to 150 M12
32 to 40
(283 to 354)
2A0360
R/L1, S/L2, T/L3 240 95 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 240 95 to 300
–, +1 125 to 300
+3 70 to 300 M10
18 to 23
(159 to 204)
120 120 to 240 M12
32 to 40
(283 to 354)
2A0415
R/L1, S/L2, T/L3 120 × 2P 95 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 300 95 to 300
–, +1 150 to 300
+3 70 to 300 M10
18 to 23
(159 to 204)
120 120 to 240 M12
32 to 40
(283 to 354)
<1> When an EMC filter is installed, additional measures must be taken in order to comply with IEC61800-5-1. Refer to EMC Filter Installation
on page 477.
Model
CIMR-T
Terminal
Recommended Gauge
mm
2
Applicable
Gauge
mm
2
Screw
Size
Tightening
Torque
Nxm (lb.in.)
4A0002
4A0004
R/L1, S/L2, T/L3 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 2.5 2.5 to 6
–, +1, +2 2.5 to 6
B1, B2 2.5 to 6
2.5
<1> 2.5 to 4
4A0005
4A0007
4A0009
R/L1, S/L2, T/L3 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 2.5 2.5 to 6
–, +1, +2 2.5 to 6
B1, B2 2.5 to 6
2.5
<1> 2.5 to 6
4A0011
R/L1, S/L2, T/L3 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 2.5 2.5 to 6
–, +1, +2 2.5 to 6
B1, B2 2.5 to 6
2.5
<1> 2.5 to 6
Model
CIMR-T
Terminal
Recommended Gauge
mm
2
Applicable
Gauge
mm
2
Screw
Size
Tightening
Torque
Nxm (lb.in.)
