6.4.9 Motor Code Selection (MTR: C1-25)
6 -12
Precautions when Changing the Motor Code
After changing the Motor code, be sure to turn OFF the control power supply. Next, check that the Digital
Operator display is no longer lit, and then turn ON the power supply again. This operation will enable the new
Motor code.
Table 6.4 Motor Codes for Standard Spindle Motors
Voltage
Class
Motor Inverter
Capacity
Inverter
Capacity
Selection
(C1-56)
Motor Model Motor
Code
(C1-25)
Motor Max.
Speed
(min
−1
)
30 min./
Continuous
Rated Out-
put (kW)
Load Fac-
tor Meter
Max. Value
(%)
200 V
Standard
23P7 04 UAASKA-04FZ
j
001 8,000 3.7/2.2 202
25P5 05 UAASKA-06FZj 002 8,000 5.5/3.7 178
27P5 06 UAASKA-08FZ
j
003 8,000 7.5/5.5 164
2011 07 UAASKA-11FZj 004 6,000 11/7.5 176
2015 08 UAASKA-15FZ
j
005 6,000 15/11 164
2018 09 UAASKA-19FZ
j
006 6,000 18.5/15 148
2022 0A UAASKA-22FZ
j
007 6,000 22/18.5 143
2030 0B
UAASKJ-30FZj 008 4,500 30/22 164
2037 0C UAASKJ-37FZj 009 4,500 37/30 148
Winding
selection
25P5 05 UAASKB-06FZj 062 6,000 (1,500) 5.5/3.7 178
selection
27P5 06 UAASKB-08FZj 063 6,000 (1,500) 7.5/5.5 164
2011 07 UAASKB-11FZj 064 6,000 (1,500) 11/7.5 176
2015 08 UAASKB-15FZj 065 4,800 (1,000) 15/11 164
2018 09 UAASKB-19FZj 066 4,800 (1,000) 18.5/15 148
2022 0A UAASKB-22FZj 067 4,800 (1,000) 22/18.5 143
2030 0B UAASKB-30FZj 068 4,800 (1,000) 30/20 180
400 V
Standard
45P5 25 UAASKA-06FZjOOE 102 8,000 5.5/3.7 178
47P5 26 UAASKA-08FZjOOE 103 8,000 7.5/5.5 164
4011 27 UAASKA-11FZjOOE 104 6,000 11/7.5 176
4015 28 UAASKA-15FZjOOE 105 6,000 15/11 164
4018 29 UAASKA-19FZjOOE 106 6,000 18.5/15 148
4022 2A UAASKA-22FZjOOE 107 6,000 22/18.5 143
4030 2B UAASKJ-30FZjOOE 108 4,500 30/22 164
4037 2C UAASKJ-37FZjOOE 109 4,500 37/30 148
4045 2D UAASKJ-45FZj OOE 10A 4,500 45/37 146
Winding
selection
45P5 25 UAASKB-06FZjOOE 162 6,000 (1,500) 5.5/3.7 178
selection
47P5 26 UAASKB-08FZjOOE 163 6,000 (1,500) 7.5/5.5 164
4011 27 UAASKB-11FZjOOE 164 6,000 (1,500) 11/7.5 176
4015 28 UAASKB-15FZjOOE 165 4,800 (1,000) 15/11 164
4018 29 UAASKB-19FZjOOE 166 4,800 (1,000) 18.5/15 148
4022 2A UAASKB-22FZj OOE 167 4,800 (1,000) 22/18.5 143
4030 2B UAASKB-30FZjOOE 168 4,800 (1,000) 30/20 180
Note: Values in parentheses are the maximum speed (min
−1
) of the low-speed windings.
The maximum value of the load factor meter = (30-min rated output x 120%)/(continuous rated output) (%)
