YASKAWA VS-656MR5

9-1
9
Magnetic Sensor Orientation Control
This chapter explains control methods using a Magnetic Sensor Orientation
Card.
9.1 Device Configuration 9 -2..................
9.2 Standard Connections 9 -3.................
9.3 Orientation Specifications 9 -4..............
9.3.1 Standard Specifications 9 -4......................
9.3.2 Magnet Specifications 9 -4........................
9.3.3 Magnetic Sensor Specifications 9 -5................
9.4 Dimensions 9 -6..........................
9.4.1 Magnetic Sensor Orientation Card (ETC62614X) 9 -6
9.4.2 Magnet 9 -6.....................................
9.4.3 Magnetic Sensor 9 -7............................
9.5 Connections between Devices 9 -8..........
9.5.1 Magnetic Sensor Signal 9 -8......................
9.5.2 Stop Position References 9 -8.....................
9.6 Control Signal Connector Terminal
Arrangement 9 -9.........................
9.7 Magnet and Magnetic Sensor Mountings 9 -10.
9.8 Mounting Precautions 9 -11.................
9.9 Stop Position Reference Signal Details 9 -13..
9.10 Functions 9 -14............................
9.10.1 Fixed Position Stopping Operation Using
the Magnetic Sensor 9 -
14
.......................
9.10.2 User-set Position Stop Control Using
Incremental Operations 9
-15
.........................
9.11 Magnetic Sensor Orientation Control Mode
Adjustment Procedure 9 -16.................
9
