Handling
2.1.1 Inverter Nameplate Information
2-2
2.1 Confirmation upon Delivery
CAUTION
D Do not install any Inverter or Converter which is damaged or has missing parts.
Failure to observe this caution may result in personal injury or equipment damage.
Check the following items as soon as the Inverter and Converter are delivered.
Table 2.1 Checks
Check points Description
Does the Inverter model number corre-
spond with the purchase order?
Check the model number on the name plate on the side of the Inverter and
that of the Converter. (See 2.1.1).
Are any parts damaged? Visually check the exterior and verify that there was no damage during
transport.
Are any screws or other components
loose?
Use a screwdriver or other tools to check for tightness.
If any of the above checkpoints are not satisfactory, contact your Yaskawa representative.
2.1.1 Inverter Nameplate Information
J
Nameplate Information
Example of a Model for 200 VAC, 10HP (7.5 kW)
Serial No.
Inverter Model
Input Spec.
Inverter Spec.
Output Spec.
Mass
PROM No.
PRG : 0083
YASKAWA ELECTRIC CORPORATION
INPUT : DC 270−325 V 9.3 kW
MODEL : CIMR−M5A27P5
OUTPUT : AC 3PH 0−230 V 8.8 kVA
SER NO : N32762−000/V0004 MASS : 5 kg (11 lb)
MADE IN JAPAN
SPEC : 27P55E
720003
Fig 2.1 Inverter Nameplate
J
Model Designations
Voltage
2 3-phase 200 V class
CIMR - M5 N 2 7P5
Inverter
VS-626M5 Series
Symbol Max. applicable motor output
3P7 5HP (3.7kW)
5P5
to
045
7.5HP (5.5kW)
to
60HP (45kW)
Symbol
Symbol
A
Specifications
For stand alone system
N
For NC system (YENET 1200)
4 3-phase 400 V class
(“P” indicates a decimal point.)
Fig 2.2 Inverter Model Numbers
2
To Next Page
