YASKAWA VS-656MR5

Specifications
14.1.1 Standard Drive Series
14 -2
14.1 Drives
This section provides the standard specifications of the Drives.
14.1.1 Standard Drive Series
The following table lists the specifications for the Standard Drive Series.
Table 14.1 Standard 200 V Series
Model UAASK FZ A-04 A-06 A-08 A-11 A-15 A-19 A-22 J-30 J-37
Rated
Output
*2
30-minute Rating (S2)
50%ED Rating (S3)
5
*1
(3.7)
7.5
(5.5)
10
(7.5)
15
(11)
20
(15)
25
(18.5)
30
(22)
40
(30)
50
(37)
2
HP
(kW)
Continuous Rating (S1)
3
(2.2)
5
(3.7)
7.5
(5.5)
10
(7.5)
15
(11)
20
(15)
25
(18.5)
30
(22)
40
(30)
Rated
speed
Base Speed 1500 1150
spee
d
(min
−1
)
Maximum Speed 8000 6000 4500
Out
p
ut Tor
q
ue at
N·m 14.0 23.5 35.0 47.7 70.0 95.0 117.6 182.3 249.1
Motor
Output
T
orque
at
Base Speed Con-
tinuous Rating
lb·ft
(kgf·m)
10.4
(1.43)
17.4
(2.40)
25.8
(3.57)
35.8
(4.87)
51.7
(7.14)
70.6
(9.74)
86.9
(12.0)
134
(18.6)
183
(25.4)
Rotor Inertia J (GD
2
/4) lb·ft
2
(kg·m
2
)
0.209
(0.0088)
0.411
(0.0173)
0.617
(0.026)
0.759
(0.032)
1.614
(0.068)
1.970
(0.083)
2.326
(0.098)
6.122
(0.258)
8.068
(0.34)
Overload Capacity 120%, 60s of 30-minute rating
Vibration (µ·m)
V5 V10
Noise Level 75dB (A) or less 80dB (A) or less
Ambient Temperature, Humidity
0°C to +40°C (32°F to 104°F), 95% or less (non-condensing)
Approx. Mass lb
(kg)
71
(32)
119
(54)
130
(59)
150
(68)
207
(94)
238
(108)
269
(122)
481
(218)
580
(263)
* 1. 15-minute rating (50%ED)/continuous rating for model UAASKA-04FZ 5/3HP (3.7/2.2kW)
* 2. Rated output power is guaranteed when input voltage is three-phase, 200 V (50/60 Hz), 220 V (50/60 Hz), 230 V (60 Hz). If
input voltage is lower than 200 V, rated output power is not guaranteed.
14
