YASKAWA VS-656MR5

2.1 Confirmation upon Delivery
2-3
J
Inverter Specification Designation
2 7P5 5 E *
Revision symbol
Symbol
Enclosure
External heatsink
cooling type
0 Open chassis type
5
Voltage
2 3-phase 200 V class
Symbol
Symbol Max. applicable motor output
4 3-phase 400 V class
3P7 5HP (3.7kW)
5P5
to
045
7.5HP (5.5kW)
to
60HP (45kW)
(“P” indicates a decimal point.)
* For special specifications, a spec. sheet No.
appears on the nameplate.
Fig 2.3 Inverter Specifications
2.1.2 Converter Nameplate Information
J
Nameplate Information
Example of a Model for 200 VAC, 15 HP (11 kW)
Serial No.
Converter Model
Input Spec.
Converter Spec.
Output Spec.
PROM number
Mass
YASKAWA ELECTRIC CORPORATION
INPUT : AC 3PH 200-220 V 50 Hz
200-230 V 60 Hz 19 kVA
MODEL : CIMR-MR5A2011
OUTPUT : DC 270-325 V 13.6 kW
SER NO : N32764-000/V0004 MASS : 12 kg (26.5 lb)
MADE IN JAPAN
SPEC : 20115E
PRG : 0120
Fig 2.4 Converter Nameplate
J
Model Designations
Voltage
2 3-phase 200 V class
CIMR - MR5 N 2 011
Converter
VS-656MR5 Series
Symbol Max. applicable motor output
3P7 5HP (3.7kW)
5P5
to
045
7.5HP (5.5kW)
to
60HP (45kW)
Symbol
Symbol
A
Specifications
For stand alone system
N
For NC or stand-alone system
4 3-phase 400 V class
(“P” indicates a decimal point.)
Fig 2.5 Converter Model Numbers
2
