1.1 Overview
1-3
J
International Standards
The Inverter and Converter meet EMC and low-voltage directive requirements, allowing machinery
manufacturers to easily acquire CE marking certification.
1.1.2 Inverter Models
Inverter models are offered in both 200 and 400 V classes. Both M5A models for independent drive with
analog speed references and M5N models for NC systems using YENET1200 serial communications are
available in both classes. M5A and M5N models differ from each other in the host control device and in
connection methods.
Table 1.1 Inverter Models
VS-626M5 Inverter Model Numbers
*
Type
Voltage
Class
30-minute
Rated
Output (kW)
Model Number
Open Chassis
CIMR-M5jjjjj5
Enclosed Wall-mounted
CIMR-M5jjjjj0
3.7 CIMR-M5A23P7 CIMR-M5A23P75 CIMR-M5A23P70
5.5 CIMR-M5A25P5 CIMR-M5A25P55 CIMR-M5A25P50
7.5 CIMR-M5A27P5 CIMR-M5A27P55 CIMR-M5A27P50
11 CIMR-M5A2011 CIMR-M5A20115 CIMR-M5A20110
200 V class
15 CIMR-M5A2015 CIMR-M5A20155 CIMR-M5A20150
18.5 CIMR-M5A2018 CIMR-M5A20185 CIMR-M5A20180
22 CIMR-M5A2022 CIMR-M5A20225 CIMR-M5A20220
30 CIMR-M5A2030 CIMR-M5A20305 CIMR-M5A20300
M5A
37 CIMR-M5A2037 CIMR-M5A20375 CIMR-M5A20370
M5A
5.5 CIMR-M5A45P5 CIMR-M5A45P55 CIMR-M5A45P50
7.5 CIMR-M5A47P5 CIMR-M5A47P55 CIMR-M5A47P50
11 CIMR-M5A4011 CIMR-M5A40115 CIMR-M5A40110
15 CIMR-M5A4015 CIMR-M5A40155 CIMR-M5A40150
400 V class
18.5 CIMR-M5A4018 CIMR-M5A40185 CIMR-M5A40180
22 CIMR-M5A4022 CIMR-M5A40225 CIMR-M5A40220
30 CIMR-M5A4030 CIMR-M5A40305 CIMR-M5A40300
37 CIMR-M5A4037 CIMR-M5A40375 CIMR-M5A40370
45 CIMR-M5A4045 CIMR-M5A40455 CIMR-M5A40450
3.7 CIMR-M5N23P7 CIMR-M5N23P75 CIMR-M5N23P70
5.5 CIMR-M5N25P5 CIMR-M5N25P55 CIMR-M5N25P50
7.5 CIMR-M5N27P5 CIMR-M5N27P55 CIMR-M5N27P50
11 CIMR-M5N2011 CIMR-M5N20115 CIMR-M5N20110
200 V class
15 CIMR-M5N2015 CIMR-M5N20155 CIMR-M5N20150
18.5 CIMR-M5N2018 CIMR-M5N20185 CIMR-M5N20180
22 CIMR-M5N2022 CIMR-M5N20225 CIMR-M5N20220
30 CIMR-M5N2030 CIMR-M5N20305 CIMR-M5N20300
M5N
37 CIMR-M5N2037 CIMR-M5N20375 CIMR-M5N20370
M5N
5.5 CIMR-M5N45P5 CIMR-M5N45P55 CIMR-M5N45P50
7.5 CIMR-M5N47P5 CIMR-M5N47P55 CIMR-M5N47P50
11 CIMR-M5N4011 CIMR-M5N40115 CIMR-M5N40110
15 CIMR-M5N4015 CIMR-M5N40155 CIMR-M5N40150
400 V class
18.5 CIMR-M5N4018 CIMR-M5N40185 CIMR-M5N40180
22 CIMR-M5N4022 CIMR-M5N40225 CIMR-M5N40220
30 CIMR-M5N4030 CIMR-M5N40305 CIMR-M5N40300
37 CIMR-M5N4037 CIMR-M5N40375 CIMR-M5N40370
45 CIMR-M5N4045 CIMR-M5N40455 CIMR-M5N40450
* Specify all standards through the construction when ordering.
