YASKAWA VS-656MR5

14.2 Standard Motor Specifications
14 -19
14.2.3 Output and Torque Speed Characteristics
The output and torque speed characteristics are shown in the following graphs.
J
Standard Motors
The output characteristics are the same for both the 200 V and 400 V Series. Note that 3.7/2.2 kW is avail-
able only for the 200 V Series, and 45/37 kW is available only for the 400 V Series.
3.7/2.2 kW (200 V Series)
1500
0
2
4
8000
(kgf
•m) (N•m)
00
14.0
23.5
28.3
1.43
2.40
2.88
1500 8000
4.4 kW (1 min. rating)
3.7 kW (15 min. rating, 50% ED)
2.2 kW (Continuous rating)
Motor speed (min
−1
)
Output (kW)
1 min. rating
Continuous
rating
Motor speed (min
−1
)
Torque
15 min. rating (50% ED)
5.5/3.7 kW (200 V and 400 V Series)
1500
0
2
4
6
80006000
4.44 kW
3.7 kW
2.5 kW
1500
00
23.5
35.0
42.0
2.40
3.57
4.28
80006000
(kgf
•m) (N•m)
6.6 kW (1 min. rating)
5.5 kW (30 min. rating, 50% ED)
3.7 kW (Continuous rating)
Motor speed (min
−1
)
Output (kW)
1 min. rating
Continuous
rating
30 min. rating (50% ED)
Motor speed (min
−1
)
Torque
14
