1.1.3 Converter Models
1-4
1.1.3 Converter Models
Converter models are offered in both into 200 and 400 V classes. Both MR5A models for independent
drives with no 24-V control power supply and MR5N models for NC systems with a 24-V control power
supply are available.
Table 1.2 Converter Models
VS-656MR5 Inverter Mode Numbers
*
Type
Voltage
Class
30-minute
Rated
Output (kW)
Model Number
Open Chassis
CIMR-MR5jjjjj5
Enclosed Wall-mounted
CIMR-MR5jjjjj0
3.7 CIMR-MR5A23P7 CIMR-MR5A23P75 CIMR-MR5A23P70
5.5 CIMR-MR5A25P5 CIMR-MR5A25P55 CIMR-MR5A25P50
7.5 CIMR-MR5A27P5 CIMR-MR5A27P55 CIMR-MR5A27P50
11 CIMR-MR5A2011 CIMR-MR5A20115 CIMR-MR5A20110
200 V class
15 CIMR-MR5A2015 CIMR-MR5A20155 CIMR-MR5A20150
18.5 CIMR-MR5A2018 CIMR-MR5A20185 CIMR-MR5A20180
22 CIMR-MR5A2022 CIMR-MR5A20225 CIMR-MR5A20220
30 CIMR-MR5A2030 CIMR-MR5A20305 CIMR-MR5A20300
MR5A
37 CIMR-MR5A2037 CIMR-MR5A20375 CIMR-MR5A20370
MR5A
5.5 CIMR-MR5A45P5 CIMR-MR5A45P55 CIMR-MR5A45P50
7.5 CIMR-MR5A47P5 CIMR-MR5A47P55 CIMR-MR5A47P50
11 CIMR-MR5A4011 CIMR-MR5A40115 CIMR-MR5A40110
15 CIMR-MR5A4015 CIMR-MR5A40155 CIMR-MR5A40150
400 V class
18.5 CIMR-MR5A4018 CIMR-MR5A40185 CIMR-MR5A40180
22 CIMR-MR5A4022 CIMR-MR5A40225 CIMR-MR5A40220
30 CIMR-MR5A4030 CIMR-MR5A40305 CIMR-MR5A40300
37 CIMR-MR5A4037 CIMR-MR5A40375 CIMR-MR5A40370
45 CIMR-MR5A4045 CIMR-MR5A40455 CIMR-MR5A40450
3.7 CIMR-MR5N23P7 CIMR-MR5N23P75 CIMR-MR5N23P70
5.5 CIMR-MR5N25P5 CIMR-MR5N25P55 CIMR-MR5N25P50
7.5 CIMR-MR5N27P5 CIMR-MR5N27P55 CIMR-MR5N27P50
11 CIMR-MR5N2011 CIMR-MR5N20115 CIMR-MR5N20110
200 V class
15 CIMR-MR5N2015 CIMR-MR5N20155 CIMR-MR5N20150
18.5 CIMR-MR5N2018 CIMR-MR5N20185 CIMR-MR5N20180
22 CIMR-MR5N2022 CIMR-MR5N20225 CIMR-MR5N20220
30 CIMR-MR5N2030 CIMR-MR5N20305 CIMR-MR5N20300
MR5N
37 CIMR-MR5N2037 CIMR-MR5N20375 CIMR-MR5N20370
MR5N
5.5 CIMR-MR5N45P5 CIMR-MR5N45P55 CIMR-MR5N45P50
7.5 CIMR-MR5N47P5 CIMR-MR5N47P55 CIMR-MR5N47P50
11 CIMR-MR5N4011 CIMR-MR5N40115 CIMR-MR5N40110
15 CIMR-MR5N4015 CIMR-MR5N40155 CIMR-MR5N40150
400 V class
18.5 CIMR-MR5N4018 CIMR-MR5N40185 CIMR-MR5N40180
22 CIMR-MR5N4022 CIMR-MR5N40225 CIMR-MR5N40220
30 CIMR-MR5N4030 CIMR-MR5N40305 CIMR-MR5N40300
37 CIMR-MR5N4037 CIMR-MR5N40375 CIMR-MR5N40370
45 CIMR-MR5N4045 CIMR-MR5N40455 CIMR-MR5N40450
* Specify all standards through the construction when ordering.
