YASKAWA VS-656MR5 - Magnetic Sensor

9.4 Dimensions
9-7
9.4.3 Magnetic Sensor
J
FS-1378C
Magnet direction of
travel
FSH-1378C Magnetic
Sensor Head
1-groove
pin
Mounting cutaway
6-core LCKV cable
FSD-1378C
Detector
STP-7 Waterproof Ground
(Rappu)
TRC116-21A 10-7M Recep-
tacle
(Tajimimusen)
TRC116-12A 10-7F Plug
(Tajimimusen)
Detail at A
36
18
6
5
1
40
50
60
1
4.5
2.7
22
16
4
SPC 0.5 t
φ12
18
2−φ5.4
10
1037.5
37.5
95
A
25
13
1
2−M4
28
φ20
500 mm
(Unit: mm)
φ
φ
Fig 9.6 Dimensions of FS-1378C Magnetic Sensor
J
FS-200A
4-core cabtire cable
Diameter: 6 mm
Length: 5 m
4.2 x 5 oblong mounting hole
11.5
22.5
MACOME
MAGNETIC FLUX
SENSOR FS−200A
27
35
42
50
52.3
1
4.2 mounting hole
(Unit: mm)
Fig 9.7 Dimensions of FS-200A Magnetic Sensor
9
φ
