YASKAWA VS-656MR5

14.1 Drives
14 -3
Model CIMR-M5j
*
1
23P7 23P5 27P5 2011 2015 2018 2022 2030 2037
Continuous Rated Input Cur-
rent (A)
17.6 17.6 26.2 35.7 52.4 71.4 88.1 104.8 142.8
Continuous Rated Output Cur-
rent (A)
21 21 31 40 56 80 98 113 160
Control Method Sine wave PWM Inverter (Vector control)
r
ter
Speed Control Range 40 min
−1
to maximum motor speed
nver
t
Speed Regulation 0.2% maximum speed or less
I
n
Overload Capacity 120%, 60s of 30-minute rating
Approx. Mass lb (kg) 11 (5) 27 (12) 35 (16) 57 (26)
Dimensions in
inches
Width 3.94 (100) 5.91 (150)
7.84
(200)
11.81
(300)
inches
(mm)
*2
Height 13.78 (350)
(
mm
)
2
Depth 12.60 (320)
Model CIMR-MR5j*
1
23P7 25P5 27P5 2011 2015 2018 2022 2030 2037
Required Power Capacity
(kVA)
7 9 12 19 24 30 36 48 60
Continuous Rated Input Cur-
rent (A)
13.3 13.3 19.7 26.8 39.3 53.6 66.1 78.6 107.2
Continuous Rated Output Cur-
rent (A)
17.6 17.6 26.2 35.7 52.4 71.4 88.1 104.8 142.8
Power Supply
Three-phase, 200 VAC (50/60Hz); 220 VAC (50/60Hz); 230 VAC (60Hz)
(Allowable voltage fluctuation: +10% to −15%, allowable frequency fluctuation: ±5%,
Line-to-line voltage unbalance: 5% or less)
Controller
o
nverter
*
3
Control Power Supply
Single-phase, 200 VAC (50/60Hz); 220 VAC (50/60Hz); 230 VAC (60Hz)
(Allowable voltage fluctuation: +10% to −15%, allowable frequency fluctuation: ±5%)
Required power capacity: 100 VA (for independent drive system)
250 VA (for NC system)
C
Co
Control Method
Power regenerative control (120_ current conduction)
Overload Capacity 120% for one minute, 200% for one second
Approx. Mass lb (kg) 11 (5) 27 (12) 35 (16) 57 (26)
Dimensions in
inches
Width 3.94 (100) 5.91 (150)
7.84
(200)
11.81
(300)
inches
(mm)
*2
Height 13.78 (350)
(
mm
)
2
Depth 12.60 (320)
Power Supply AC Reactor
Code No.
X010057 X010058 X010059 X010060 X010061 X010062 X010063 X010064 X010120
Model CIMR-M5j
*
1
CIMR-MR5j
*
1
23P7 25P5 27P5 2011 2015 2018 2022 2030 2037
Ambient Temperature
0°Cto55°C (32°F to 131°F) (not frozen)
n
Heatsink Intake Air Tempera-
ture
0°Cto45°C (32°Fto113°F)
m
mon
Storage Temperature
*4
−20°Cto60°C(−4°F to 140°F)
C
om
m
Humidity 90% or less (non-condensing)
C
Location Indoor (protected from corrosive gases and dust), elevation: 1000 m (3280 ft) or less
Vibration 9.8 m/s
2
(1G) at 10 to less than 20 Hz, up to 2 m / s
2
(0.2G) at 20 to 50 Hz
Protective Structure
IEC IP00
(Protected so that parts of the human body cannot reach electrically charged parts from the front)
* 1. A: For stand-alone drive system N: for NC system
* 2. Dimensions of External Heatsink Cooling Type. Refer to 14.1.3 Dimensions for Open Chassis Type.
* 3. An AC reactor is required between Converter and main circuit power supply.
* 4. Temperature during shipping.
14
