YASKAWA VS-656MR5

Specifications
14.2.4 Dimensions
14 -34
J
Winding Selection Motor, Foot-mounted Type
jD
KI
J
E
M
G
C
H
L
A
R
Q
B
KD
XB
F
N
J
E
F
W
QK
QR
Q
S
3-m screw
Depth 10
U
Details of Shaft
T
4-φZ:
Diameter of
mounting hole
Unit: mm (inch)
Rated Output kW
0
05
30 min.
Rating
Continuous
Rating
A B
0
−0.5
C
D E F G H J KD L M N R XB Z KI
5.5 3.7
261
(10.3)
196
(7.72)
160
(6.3)
260
(10.2)
127
(5)
89
(3.5)
16
(0.63)
341
(13.4)
55
(2.17)
42.5
(1.67)
568
(22.4)
290
(11.4)
223
(8.78)
307
(12.1)
108
(4.25)
15
(0.59)
250
(9.84)
7.5 5.5
283
(11.1)
212
(8.35)
160
(6.3)
260
(10.2)
127
(5)
105
(4.13)
16
(0.63)
341
(13.4)
55
(2.17)
42.5
(1.67)
606
(23.9)
290
(11.4)
255
(1)
323
(12.7)
108
(4.25)
15
(0.59)
250
(9.84)
11 7.5
310.5
(12.2)
246.5
(9.7)
160
(6.3)
260
(10.2)
127
(5)
139.5
(5.49)
16
(0.63)
341
(13.4)
55
(2.17)
42.5
(1.67)
668
(26.3)
290
(11.4)
324
(12.8)
357.5
(14.1)
108
(4.25)
15
(0.59)
250
(9.84)
15 11
406
(16)
246
(9.69)
180
(7.09)
320
(12.6)
139.5
(5.49)
127
(5)
16
(0.63)
407
(16)
55
(2.17)
61
(2.4)
794
(31.3)
320
(12.6)
298
(11.7)
388
(15.3)
121
(4.76)
19
(0.75)
320
(12.6)
18.5 15
378
(14.9)
302
(11.9)
225
(8.86)
380
(15)
178
(7.01)
155.5
(6.12)
21
(0.83)
505
(19.9)
75
(2.95)
61
(2.4)
822.5
(32.4)
420
(16.5)
425
(16.7)
444.5
(17.5)
149
(5.87)
24
(0.94)
385
(15.2)
22 18.5
409
(16.1)
321
(12.6)
225
(8.86)
380
(15)
178
(7.01)
174.5
(6.87)
21
(0.83)
505
(19.9)
75
(2.95)
61
(2.4)
872.5
(34.4)
420
(16.5)
465
(18.3)
463.5
(18.2)
149
(5.87)
24
(0.94)
385
(15.2)
30 20
409
(16.1)
321
(12.6)
225
(8.86)
380
(15)
178
(7.01)
174.5
(6.87)
21
(0.83)
505
(19.9)
75
(2.95)
61
(2.4)
872.5
(34.4)
420
(16.5)
465
(18.3)
463.5
(18.2)
149
(5.87)
24
(0.94)
385
(15.2)
Rated Output kW Shaft Dimensions
30
min.
Rating
Continuous
Rating
Q QK QR S T U W d m
5.5 3.7
110
(4.33)
90
(3.54)
1
(0.039)
0
−0.016
48
9
(0.35)
5.5
(0.22)
14
(0.55)
40
(1.57)
M5
7.5 5.5
110
(4.33)
90
(3.54)
1
(0.039)
0
−0.016
48
9
(0.35)
5.5
(0.22)
14
(0.55)
40
(1.57)
M5
11 7.5
110
(4.33)
90
(3.54)
1
(0.039)
+0.030
+0.011
55
10
(0.39)
6
(0.24)
16
(0.63)
45
(1.77)
M5
15 11
140
(5.51)
110
(4.33)
2
(0.079)
+0.030
+0.011
60
11
(0.43)
7
(0.28)
18
(0.71)
50
(1.97)
M6
18.5 15
140
(5.51)
110
(4.33)
1
(0.039)
+0.030
+0.011
70
12
(0.47)
7.5
(0.3)
20
(0.79)
60
(2.36)
M6
22 18.5
140
(5.51)
110
(4.33)
1
(0.039)
+0.030
+0.011
70
12
(0.47)
7.5
(0.3)
20
(0.79)
60
(2.36)
M6
30 20
140
(5.51)
110
(4.33)
1
(0.039)
+0.030
+0.011
70
12
(0.47)
7.5
(0.3)
20
(0.79)
60
(2.36)
M6
Notes:1. The shaft key and the key way are standard JIS B 1301-1996 models.
2. External dimensions are the same for both the 200 V and 400 V Series.
