YASKAWA VS-656MR5

14.3 Options and Peripheral Units
14 -51
J
Dimensions
The Busbar and Cable dimensions are given in the following table.
Table 14.23 Busbar and Cable Dimensions
Code
Number
Special Busbar Flat Cable P1N1 Power Supply
Cable
Cutaway
Diagram
Dimensions (mm (inches))
No. Dimen-
sions L in
No. Dimen-
sions L in
No.
Diagram
L L1 L2
sions
L
in
mm (in-
ches)
sions
L
in
mm (in-
ches)
72626-W100100
1 120 (4.72) 100 (3.94) --- 2 100 (3.94) 1 150 (5.91) 1
72626-W100150
2 167.5 (6.59) 122.5 (4.82) --- 2 180 (7.09) 1 150 (5.91) 1
72626-W100200
2 217.5 (8.56) 172.5 (6.79) --- 2 230 (9.06) 1 150 (5.91) 1
72626-W100250
2 267.5 (10.5) 222.5 (8.76) --- 2 280 (11) 1 150 (5.91) 1
72626-W100300
4 317.5 (12.5) 122.5 (4.82) 98.5 (3.88) 2 330 (13) 1 150 (5.91) 1
72626-W150100
2 147.5 (5.81) 102.5 (4.04) --- 2 100 (3.94) 1 250 (9.84) 1
72626-W150150
3 195 (7.68) 125 (4.92) --- 2 180 (7.09) 1 250 (9.84) 1
72626-W150200
3 245 (9.65) 175 (6.89) --- 2 230 (9.06) 1 300 (11.8) 1
72626-W150300
5 345 (13.6) 125 (4.92) 101 (3.98) 2 330 (13) 1 350 (13.8) 1
72626-W250100
2 147.5 (5.81) 102.5 (4.04) --- 2 100 (3.94) 1 300 (11.8) 1
72626-W250150
3 195 (7.68) 125 (4.92) --- 2 180 (7.09) 1 300 (11.8) 1
72626-W250250
3 295 (11.6) 225 (8.86) --- 2 280 (11) 1 300 (11.8) 1
72626-W300100
4 297.5 (11.7) 102.5 (4.04) 78.5 (3.09) 2 100 (3.94) 1 350 (13.8) 1
72626-W300150
5 345 (13.6) 125 (4.92) 101 (3.98) 2 180 (7.09) 1 350 (13.8) 1
72626-W300200
5 395 (15.6) 175 (6.89) 151 (5.94) 2 230 (9.06) 1 350 (13.8) 1
72626-W300300
6 495 (19.5) --- --- 2 330 (13) 1 350 (13.8) 1
14
