YOKOGAWA AQ7260 OTDR User Manual

Chapter 3 PERFORMING MEASUREMENTS
3-7
3.4 Connecting an Optical Fiber to the Instrument
[Step 3]
This section explains how to connect the optical fiber to be measured to the instrument.
Cleaning the Optical Connector and Adapter
1. Check the type of the optical adapter.
Before cleaning the optical connector and adapter, make sure that the connector of
the optical fiber to be measured has the same type as that of the optical adapter. If
not, replace the optical adapter with one of the same type.
For the method of replacing the optical adapter, refer to page 1-16.
2. Clean the optical connector and adapter.
For the method of cleaning the optical connector and adapter, refer to pages 1-9
and 1-11.
Refer
Refer
