YOKOGAWA AQ7260 OTDR User Manual

Chapter 3 PERFORMING MEASUREMENTS
3-68
When “AUTO” is Selected for “EVENT SEARCH”
When average measurement is completed successfully with “AUTO” currently selected for
“EVENT SEARCH”, events will be searched and displayed as shown below.
In the example of the above window, both trace and event list are displayed.
It is possible to display an event list only or a trace only.
For the method of displaying an event list only or a trace only, refer to pages 3-106
and 5-3.
1
2
3
4 5 6 7 8 9 10 11
TIP
Refer
