Chapter 7 USING USEFUL FUNCTIONS
7-11
7.4 Using the Label Fixed Form Input Function
When labels are added to traces, they will be stored in the internal memory automatically.
The label fixed form input function allows you to import a label from the memory (edit it if
necessary) and add it to the current trace.
This section explains how to select a label that has been entered before.
Up to 100 labels can be stored in the internal memory.
1. Press [MODE] to locate the cursor to “TRACE”.
2. Press [F2] (LABEL).
A window allowing you to enter a label will appear.
3. Press [F3] (FIXED FORM INPUT).
A list of labels that were entered before will appear.
The list shows labels in order, with the latest label at the top of the list.
4. Locate the cursor to the desired label by using the rotary knob or [S] / [T].
I wonder I could use a label
that was entered before.
TIP
TIP
To Next Page
