Chapter 7 USING USEFUL FUNCTIONS
7-33
7.8 Using the Event Fix Function
When a master event is created and auto search is performed for the measured trace, this
event fix function displays the information for the same distance as the master event.
This function is useful for measurements like measurement of multi-fiber cables, in which
the distances to the events occurring in each fiber are expected to be the same.
This section explains how to create a master event and how to use it.
1. Measure the optical fiber and perform auto search.
•For the method of measuring an optical fiber and performing auto search, refer to
page 3-56.
•For the window that shows auto search results at the end of measurement, refer
to page 3-68.
2. Press [F1] (SCREEN).
A selection window will appear.
*: Indicates the default setting.
3. Locate the cursor to “LIST” by using the rotary knob or [S] / [T].
I wonder if I could get
information at the same
distance every time.
Refer
TIP
*TRACE + LIST
LIST
Selectable
screens
TRACE
To Next Page
