Chapter 3 PERFORMING MEASUREMENTS
3-35
Changing the Auto Search Conditions
Changing the Event Search Setting
Event search is a function to automatically search for events in the acquired data after
average measurement was done.
The event search setting can be changed as explained below.
♦ Example: “AUTO” → “MANUAL”
1. Locate the cursor to “EVENT SEARCH” by using the rotary knob or the arrow
key.
2. Press [ENTER].
A selection window will appear.
*: Indicates the default setting.
3. Locate the cursor to “MANUAL” by using the rotary knob or [S] / [T].
4. Press [ENTER] to register the change made to the event search setting.
TIP
*AUTO Searches events automatically at the end of average
measurement, and creates a table summarizing event
information.
Selectable event
search setting
MANUAL Displays a trace at the end of average measurement, but
does not search events.
To Next Page
