Chapter 7 USING USEFUL FUNCTIONS
7-2
7.1 Initializing the Vertical-/Horizontal-Axis Scales
This section explains how to restore the original scale of the trace that has been enlarged,
reduced or shifted.
1. Press [MODE] to locate the cursor to “MARKER”.
2.
Press [F5] (NEXT PAGE).
3. Press [F5] (AUXILIARY FUNCTION).
4. Press [F1] (SCALE INITIALIZE).
The scales will be initialized.
Both the vertical-axis and horizontal-axis scales will be initialized at the same time.
I wonder if the
vertical-/horizontal-axis scales
could be initialized easily.
TIP
To Next Page
