Chapter 1 BEFORE USING THE INSTRUMENT
1-28
1.10 Names of Instrument Parts
This section explains the name and function of each part of the instrument (front, rear, top
and right side panels). It also explains standard accessories and options.
Front View
The instrument uses a color LCD (hereafter called LCD). A filter plate is attached to
the front surface of the LCD for protection. However, if the filter plate is exposed to
strong impact, it may crack or the LCD itself may be damaged, so special care
must be taken when handling it.
Caution
1
15
13
2
7
3
14
5
4
6
8
9
1011
12
13
