Chapter 7 USING USEFUL FUNCTIONS
7-10
For Traces that Have Not Been Auto Searched
For the window that is displayed just after measurement is finished (without auto
search), refer to page 3-71.
1. Press [MODE] to locate the cursor to “MARKER”.
2. Press [F5] (NEXT PAGE).
3. Press [F5] (AUXILIARY FUNCTION).
4. Press [F5] (CURSOR LINK).
A selection window will appear.
*: Indicates the default setting.
5. Locate the cursor to “ON” by using the rotary knob or [S] / [T].
6. Press [ENTER].
The cursor link function will be enabled and “LNK” will be displayed at the left edge of
the window.
For details on “LNK”, refer to page 1-36.
7. Turn the rotary knob to move the cursor.
As the cursor moves, all the markers will move accordingly.
Refer
Refer
TIP
*OFF
Selectable
cursor link
ON
To Next Page
