Chapter 5 EDITING AUTOMATIC SEARCH RESULTS
5-23
5.4 Attaching a Comment to an Event
This instrument allows you to attach a comment (event note) to each event detected by
auto search.
This method of attaching a comment to an event is explained below.
♦ Example: Attaching a comment to event 1
A comment can consist of up to 36 characters.
1.
Measure the optical fiber and perform auto search.
•For the method of measuring an optical fiber and performing auto search, refer to
page 3-56.
•For the screen that shows auto search results at the end of measurement, refer to
page 3-68.
2.
Press [F1] (SCREEN).
A selection window will appear.
*: Indicates the default setting.
3. Locate the cursor to “LIST” by using the rotary knob or [S] / [T].
*TRACE + LIST
LIST
Selectable screens
TRACE
TIP
Caution
Refer
To Next Page
