Chapter 8 USING OPTIONS AND EXTERNAL DEVICES
8-37
Device Message
No. Function
Header
Numeric
Part
Description
3-2 Company name CORP Enters the company name. Up to 36 characters can
be entered.
The device message must be separated from the
company name using a comma “,”.
3-3 Name OP
Enters the name. Up to 36 characters can be
entered.
The device message must be separated from the
company name using a comma “,”.
3-4 Cable ID LCID Enters the cable ID. Up to 36 characters can be
entered.
The device message must be separated from the
company name using a comma “,”.
3-5 Fiber ID LFID Enters the fiber ID. Up to 36 characters can be
entered.
The device message must be separated from the
company name using a comma “,”.
3-6 Fiber type FT m Sets the fiber type.
m= 0: SMF
1: DSF
2: NZ-DSF
3: MMF
3-7 Cable code LCCD Enters the cable code. Up to 36 characters can be
entered.
The device message must be separated from the
company name using a comma “,”.
3-8 Originating location LOL Enters the originating location. Up to 36 characters
can be entered.
The device message must be separated from the
originating location using a comma “,”.
3-9 Terminating location LTL Enter the terminating location. Up to 36 characters
can be entered.
The device message must be separated from the
terminating location using a comma “,”.
3-10 Data flag LCDF m Sets the data flag.
m= 0: -
1: BC (as-Built Condition)
2: RC (as-Repaired Condition)
3: OT (Other)
3-11 Auto increment AI m Enables (ON)/disables (OFF) the LABEL auto
increment function.
m= 0: ON
1: OFF
4-1 Wavelength LAM
m Sets the measurement wavelength.
m= 0: Unit’s first wavelength
1: Unit’s second wavelength
2: Unit’s third wavelength
3: Unit’s fourth wavelength
The wavelengths that can be set vary with the
optical module used.
4-2 Filter FIL m Enables (ON)/disables (OFF) the filter.
m= 0: OFF
1: ON
4-3 Approximate method LSA m Sets the approximate method.
m= 0: Two point approximate (TPA)
1: Least squares approximate (LSA)
