YOKOGAWA GS200 - Chapter 10 USB Interface; 10.1 USB Interface Features and Specifications

10-1
IM GS210-01EN
USB Interface
10.1 USB Interface Features and Specifications
USB Interface Features
USB Storage Feature
You can access the two disks, GS200ROM and GS200RAM as external removable disks
on your PC (see section 4.4, “USB Storage Feature”).
USB-TMC Command Control Feature
You can control the GS200 by using commands from a VISA (Virtual Instrument Software
Architecture) library.
To perform USB-TMC command control, you must first install a VISA library on your PC.
USB Interface Specifications
Electrical and mechanical specifications: Conforms to USB 2.0
Connector: Type B connector (receptacle)
Number of ports: 1
Power supply: Self-powered
Connecting to a Network
Connection Cable
Use a USB cable that has a type B connector (receptacle). For the connection procedure,
see section 4.4, “USB Storage Feature.”
