11-1
IM GS210-01EN
Ethernet Interface (Option)
11.1 Ethernet Interface Features and Specifications
Ethernet Interface Features
VXI-11 Server Feature
The VXI-11 server feature is a command mnemonic stream parsing server based on the
VXI-11 protocol that allows up to five clients to connect to it on port 111.
Command Control Server Feature
The command control server feature is a command mnemonic stream parsing server that
allows up to five clients to connect to it on port 7655.
The terminator (CR, LF, or CR+LF) can be specified.
FTP Server Feature
The FTP server feature is an anonymous FTP server that allows up to five clients to
connect to it on port 21.
HTTP Server Feature
The HTTP server feature (connected to on port 80) enables you to use a Web browser to
display various GS200 information and control the GS200 remotely.
Ethernet Interface Specifications
Connector: RJ-45
Number of ports: 1
Electrical and mechanical specifications: Conforms to IEEE 802.3
Transmission system: 100BASE-TX/10BASE-T
Maximum data rate: 100 Mbps
Protocol: TCP/IP
