13-27
IM GS210-01EN
Communication Commands
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
App
Index
Overview of Registers and Queues
Name Function Write Read
Status byte — Serial polling (RQS),
*STB? (MSS)
Service request enable register Status byte mask *SRE *SRE?
Standard event register Indicates device status changes — *ESR?
Standard event enable register Standard event register mask *ESE *ESE?
Extended event register Indicates device status changes — :STATus:EVENt?
Extended event enable register Extended event register mask :STATus:ENABle :STATus:ENABle?
Condition register Current device status — :STATus:CONDition?
Output queue Stores response messages for queries Query commands Same as left
Error queue Stores error codes and error messages — :STATus:ERRor?
:SYSTem:ERRor?
Registers and Queues That Affect the
Status Byte
The following registers affect the status byte bits.
Register
Affected Status Byte Bit
Standard event register Bit 5 (ESB)
Output queue Bit 4 (MAV)
Error queue Bit 2 (EAV)
Extended event register Bit 1 (EES)
Enable Registers
The following registers are used to mask a bit so that
the bit will not affect the status byte even when it is set
to 1.
Masked Register Mask Register
Status byte
Service request enable register
Standard event register Standard event enable register
Extended event register Extended event enable register
Reading and Writing to Registers
For example, use the *ESE command to set the
standard event enable register bits to 1 and 0. Use the
*ESR? command to query whether the standard event
register bits are 1 or 0. For details on these commands,
see section 13.2.11.
13.3 Status Reports
