13.1 Program Format
13.1.1 Symbols Used in the Syntax
The following table contains the symbols that are used
in the syntax discussed mainly in section 13.2. For
details on the data, see pages 13-5 and 13-6.
Symbol Meaning Example
|
Exclusive OR
S
OURce:FUNCtion VOLTage|CURRent
Example
SOURce:FUNCTION VOLTage
[]
Can be omitted
OUTPut[:STATe]
... Can be repeated
13.1.2 Messages
Messages
Messages are used to exchange information between
the controller and the GS200. Messages that are sent
from the controller to the GS200 are called program
messages, and messages that are sent from the
GS200 back to the controller are called response
messages.
If a program message contains a message unit that
requests a response (a query), the GS200 returns
a response message upon receiving the program
message. The GS200 returns a single response
message in response to a single program message.
Program Messages
Data that is sent from the controller to the GS200 is
called a program message. The program message
format is shown below.
<PMT>
;
<Program message unit>
<Program Message Unit>
A program message consists of one or more program
message units; each unit corresponds to one
command. The GS200 executes the commands in the
order that they are received.
Separate each program message unit with a
semicolon.
For details on the syntax of program message units,
see the next section.
Example
Unit Unit
:SOURce:FUNCtion VOLTage;RANGe 100E-3<PMT>
Chapter 13 Communication Commands
13-1
IM GS210-01EN
