15.1 Source Section
DC Voltage Source
Range Range Resolution 24 h Stability 90-Day Stability 90-Day Accuracy 1-Year Accuracy Temperature
Generated ±(% of setting ±(% of setting ±(% of setting ±(% of setting Coefficient
+
μ
V) +
μ
V) +
μ
V) +
μ
V) ±(% of setting
+
μ
V)/°C
10 mV ±12.0000 mV
100 nV 0.002 + 3 0.014 + 4 0.018 + 4 0.025 + 5 0.0018 + 0.7
100 mV ±120.000 mV 1
μ
V 0.003 + 3
0.014 + 5 0.018 + 10 0.025 + 10 0.0018 + 0.7
1 V ±1.20000 V 10
μ
V 0.001 + 10
0.008 + 50 0.010 + 100 0.016 + 120 0.0009 + 7
10 V ±12.0000 V 100
μ
V 0.001 + 20
0.008 + 100 0.010 + 200 0.016 + 240 0.0008 + 10
30 V ±32.000 V 1 mV 0.001 + 50 0.008 + 200 0.010 + 500 0.016 + 600 0.0008 + 30
24 h stability is for 23°C ±1°C and when the voltage variation is within ±5%.
90-day stability and 90-day and 1-year accuracy values are for 23°C ± 5°C.
Add the temperature coefficient for 90-day and 1-year accuracy values for 5°C to 18°C and for 28°C to 40°C.
Range Maximum Output Current
Output Resistance Output Noise
DC to 10 Hz DC to 10 kHz (Reference)
10 mV ---- Approx. 2
Ω
3
μ
Vp-p 30
μ
Vp-p
100 mV ----
Approx. 2
Ω
5
μ
Vp-p 30
μ
Vp-p
1 V ±200 mA
2 m
Ω
or less
15
μ
Vp-p 60
μ
Vp-p
10 V ±200 mA
2 m
Ω
or less
50
μ
Vp-p 100
μ
Vp-p
30 V ±200 mA
2 m
Ω
or less
150
μ
Vp-p 200
μ
Vp-p
Output noise is for when measurements are turned off.
Common mode rejection ratio: 120 dB or higher (DC, 50/60 Hz)
(100 dB or higher for 30 V range)
DC Current Source
Range Range Resolution 24 h Stability 90-Day Stability 90-Day Accuracy 1-Year Accuracy Temperature
Generated ±(% of setting ±(% of setting ±(% of setting ±(% of setting Coefficient
+
μ
A) +
μ
A) +
μ
A) +
μ
A)
±(% of setting
+
μ
A)/°C
1 mA ±1.20000 mA 10 nA 0.0015 + 0.03 0.016 + 0.1
0.02 + 0.1 0.03 + 0.1 0.0015 + 0.01
10 mA ±12.0000 mA 100 nA 0.0015 + 0.3 0.016 + 0.5 0.02 + 0.5 0.03 + 0.5 0.0015 + 0.1
100 mA ±120.000 mA 1
μ
A 0.004 + 3 0.016 + 5
0.02 + 5 0.03 + 5 0.002 + 1
200 mA ±200.000 mA 1
μ
A 0.004 + 20 0.016 + 30
0.02 + 30 0.03 + 30 0.002 + 5
24 h stability is for 23°C ±1°C and when the voltage variation is within ±5%.
90-day stability and 90-day and 1-year accuracy values are for 23°C ± 5°C.
Add the temperature coefficient for 90-day and 1-year accuracy values for 5°C to 18°C and for 28°C to 40°C.
Range Maximum Output V
oltage Output Resistance Output Noise
DC to 10 Hz DC to 10 kHz (Reference)
1 mA ±30 V 100 M
Ω
or higher 0.02
μ
Ap-p 0.1
μ
Ap-p
10 mA ±30 V
100 M
Ω
or higher 0.2
μ
Ap-p 0.3
μ
Ap-p
100 mA ±30 V
10 M
Ω
or higher 2
μ
Ap-p 3
μ
Ap-p
200 mA ±30 V
10 M
Ω
or higher 10
μ
Ap-p 15
μ
Ap-p
Output noise is for when measurements are turned of
f.
Common mode rejection ratio: 100 nA/V or higher (DC, 50/60 Hz)
Chapter 15 Specifications
15-1
IM GS210-01EN
