YOKOGAWA GS200 User Manual

15.5 Interface
GP-IB Interface
Item Specifications
Electrical and mechanical Conforms to IEEE St’d 488-1987
specifications
Functional specifications SH1,
AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, and C0
Protocol Conforms to IEEE St’d 488.2-1992
Address 0 to 30
USB Interface
Item Specifications
Number of ports 1
Connector Type B connector (receptacle)
Electrical and mechanical Conforms to USB 2.0
specifications
Protocol Mass storage class, USB-TMC
Ethernet Interface
Item Specifications
Number of ports 1
Connector RJ-45 connector
Electrical and mechanical Conforms to IEEE 802.3
specifications
Transmission system
100BASE-TX/10BASE-T
Data rate 100 Mbps/10 Mbps
Protocol VXI-11 server, HTTP server, FTP server, DHCP client, and command socket
15-5
IM GS210-01EN
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
App
Index

YOKOGAWA GS200 Specifications

General

Brand	YOKOGAWA
Model	GS200
Category	Power Supply
Language	English
