15.2 Measurement Section (On models with the /
MON option)
DC Voltage Measurement
Range Measurement Resolution Input Resistance 1-Year Accuracy (1 PLC) Temperature Coefficient
Range ±(% of reading + mV) ±(% of reading + mV)/°C
30 V ±31.000 V 1 mV 10 M
Ω
or higher 0.02 + 2
0.002 + 0.1
DC Current Measurement
Range Measurement Resolution Input Resistance 1-Year Accuracy (1 PLC) Temperature Coefficient
Range ±(% of reading +
μ
A) ±(% of reading +
μ
A)/°C
200 mA ±210.00 mA 10
μ
A 2 m
Ω
or less 0.03 + 300
0.003 + 30
1 V, 10 V, 30 V source ranges only
15.3 Features
Source
Item Specifications
Function Voltage or current
Programming
Item Specifications
Maximum number of steps 10000
Program trigger External, internal timer, STEP key, or measurement end (M.End)
Internal timer 0.1 s to 3600.0 s
Slope 0 s to 3600.0 s
Measurement
Item Specifications
Function Voltage (current source mode) or current (voltage source mode)
Integration time 1 PLC to 25 PLC
Trigger Measurement timer (period: 0.1 s to 3600.0 s), measurement end, source change completion (Ready),
or communication command
Measurement delay 0 ms to 999999 ms
Storage
Up to 10000 results
Voltage sense Two-wire system and four-wire system
Auto zero Measures the internal zero reference and uses it to correct the measured value for each
measurement
NULL computation
Displays the result obtained by subtracting the NULL value from the measured value
