8-33
IM 05P02D41-01EN
Control Functions
8.8 Adjusting Auto-tuning Operation
Description
Auto-tuningType
“Normal” of auto-tuning type requires a rapidly rising PID constant. This type is useful for
processes that allow some overshooting.
On the other hand, “stable” of auto-tuning type requires a slowly rising PID constant.
Auto-tuning Output Limiter
When executing auto-tuning, the control output high and low limits can be set.
When the control output low limit > AT.OL, or AT.OH < control output high limit, auto-
tuning is limited by the control output low or high limit.
In Heating/cooling control, AT.OH and AT.OL do not work.
Note
In time proportional output, the output is turned on and off irrespective of the upper/lower limit.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
AT.TY Auto-tuning type STD
0: Normal
1: Stability
TUNE
AT.OH
Output high limit in
auto-tuning
PRO
-5.0 to 105.0% (Disabled in
Heating/cooling control)
AT.OL
Output low limit in
auto-tuning
PRO
► SP bias in auto-tuning: 6.2 Performing and Canceling Auto-tuning
8
