Alarm Functions

11.5 SettingAlarmOutputtoControlRelayTerminal

Description

The control relay terminal can be used for alarm output when it is not used for control

output.

SettingDetails

Parameter

symbol

Name

Display

level

Settingrange Menusymbol

OR.S

OUT relay function

selection

STD

Same as the setpoint for the

contact output function.

See 12.2.1, “Setting Function of

Contact Output.”

ALM

OR.D

OUT relay contact

type

PRO

0: Closes the contact when an

event occurs

1: Opens the contact when an

event occurs.

OR2.S

OUT2 relay

function selection

STD Same as OR.S.

OR2.D

OUT2 relay contact

type

PRO Same as OR.D

Parameters and Corresponding Terminals

OR.S, OR.D OUT terminal

OR2.S, OR2.D OUT2 terminal
