9.4.2 ProgramWaitintheMiddleofaSegment

Description

When the wait operation is set so that the program waits in the middle of the segment,

the wait state is automatically engaged and the program is delayed if PV drifts outside

ofapresetwaitzone.Thiswaitzoneissetwithrespecttothecurrenttargetsetpoint.If

PVreturnswithinthewaitzone,thewaitstateischangedtotheoperatingstateandthe

program resumes running.

Wait time (WT.TM1) is disabled in the middle of a segment.

Original target setpoint

Seg.1

Time

Upper-side wait zone

Lower-side wait zone

Wait operation

Seg.: Segment

Setpoint

Time event

Off

Timer stops

SettingDetails

► 9.4.1 Wait during switching between segments

9.4SettingtheWaitFunctions
