YOKOGAWA UP35A - Selecting the Initial Operation Display that Appears at Power on

To Next Page

To Previous Page

13-12

IM 05P02D41-01EN

13.1.9  SelectingtheInitialOperationDisplaythatAppearsatPowerON

Description

The initial Operation Display that appears when the power is turned on can be set.

SettingDetails

Parameter

symbol

Name

Display

level

Settingrange Menusymbol

HOME

Home Operation

Display setting

PRO

SP1: SP Display

OUT1: OUT Display

HCO: Heating/cooling OUT Display

VP: Valve Position Display

MV: Position Proportional

Computation Output Display

PID1: PID Number Display

HC1: Heater Break Alarm-1 Current

Display

HC2: Heater Break Alarm-2 Current

Display

PV: PV Analog Input Display

CS1 to CS5: SELECT Display 1 to 5

TSP: TSP Display

R.TIM: Remaining Segment-tim

Display

SEG.N: Segment Number Dispaly

R.CYC: Remaining Repetition

Display

PTN: Program Pattern Display

DISP

13.1SettingDisplayFunctions
