6-26

IM 05P02D41-01EN

6.6.3 SwitchingtoRESETOperation

SelectingbyRSTKey(UP35Aonly)

SettingDisplay

Press RST key for 1 s.

RST lamp is lit in

RESET mode.

SelectingbyMODEKey(UP32A)

SettingDisplay

PRG lamp

is lit.

RST lamp is lit.

Show the Operation Display.

Press the SET/ENTER key.

Press the MODE key.

The PTNO. (Pattern number selection)

is displayed.

Not displayed if a STOP switch is assigned to the contact input.

6.6SwitchingOperationModes
