8-37

IM 05P02D41-01EN

Control Functions

8.12

SettingControllerActionatPowerON(RestartMode)

Description

For details, see Chapter 15, “Power Failure Recovery Processing.”

SettingDetails

Parameter

symbol

Name

Display

level

Settingrange Menusymbol

R.MD Restart Mode STD

CONT: Continue action set before

power failure. (Continue operation

mode.)

MAN: Start from MAN. (Continue

operation mode.)

RESET: Start from AUTO and RESET.

Outputs the preset output value.

Set how the controller should recover

from a power failure of 5 seconds or

more.

SYS

Operation mode: PROG, RESET, LOCAL

The preset output (PO) is output in MAN or RESET mode.

Default Chapter4
