YOKOGAWA UP35A User Manual

10-23
IM 05P02D41-01EN
Output (Control and Retransmission) Functions
10
10.14.1 SettingValveOperationMode
Description
Position proportional control monitors the control output signals and the feedback signals
from the control valve and regulates to keep the valve opening and the control output
signal in agreement.
Position proportional control (output) operation mode has feedback type and estimating
type.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
V.MOD
Valveadjusting
mode
STD
0: Valve position feedback type
1: Valve position feedback type
(moves to the estimating type if
a feedback input error or break
occurs.)
2: Valve position estimating type
OUT
10.14.2 AdjustingValvePositionAutomatically
Description
The fully-closed and fully-opened positions of a valve can be set automatically by the
feedback input signal from a valve.
Thefollowingdescribestheprocedureofadjustingthevalvepositionautomatically.
(1) Verify that the wirings are correct.
(2) Set the operation mode to MAN.
(3) Settheautomaticvalvepositionadjustment(V.AT)toON.(V.ATblinksduringthe
automaticadjustment.)
(4) Whentheadjustmentiscompleted,V.ATreturnstoOFF.
 Whentheadjustmentfails,VAT.EappearsonPVdisplay.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
V.AT
Automatic
valve position
adjustment
EASY
OFF:Stopautomaticadjustment
ON:Startautomaticadjustment
OUT
10.14 Adjusting Motor-operated Valve Position (Position Proportional Output)
