YOKOGAWA UP35A - Editing the Prgram Pattern; Checking the Number of Remaining Segments; Checking the Number of Segments in Specified Pattern

9-38
IM 05P02D41-01EN
9.12 Editing the Prgram Pattern
9.12.1 CheckingtheNumberofRemainingSegments
Description
This allows checking the number of the segments unused in the controller.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
ALL.S
Number of
remaining unused
segments
PRO
0 to 20 (40 when the option “/AP”
isspecied.)
(Display only)
EDIT
9.12.2 CheckingtheNumberofSegmentsinspecifiedpattern
Description
This allows specifying the program pattern number to be displayed in the parameter
USE.S.
The parameter PTN.S is displayed when a program pattern number is specified in
the parameter USE.S. The number of segments for the specified program pattern is
displayed in USE.S.
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
PTN.S
Pattern number
designation for
comrmingnumber
of segments
PRO
0 to 2 (4 when the option “/AP” is
specied.)
(Display only)
EDIT
USE.S
Number of
segments within a
pattern
PRO
0: disable
1 to 20 (40 when the option “/AP”
isspecied.)
(Display only)
