Quick Setting Function

5.1 SettingUsingQuickSettingFunction

Description

The Quick setting function is a function to easily set the basic function of the controller.

The Quick setting function starts when the power is turned on after wiring.

The following lists the items to set using the Quick setting function.

(1) Control type (PID control, Heating/cooling control, etc.)

(2) Input function (PV input, range, scale (at voltage/current input), etc.)

(3) Output function (control output type and cycle time)

Chapter5QuickSettingFunction
