12-11
IM 05P02D41-01EN
Contact Input/Output Functions
12
12.2 SettingContactOutputFunction
12.2.1 SettingFunctionofContactOutput
Description
The contact output function works by setting a status such as an alarm to the contact
output.
Thisexplanationassumesthatthecontacttypeisenergized.(Thecontactisturnedon
when an event occurs.)
SettingDetails
ContactOutputEquippedasStandard
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
AL1.S AL1 function selection STD
See the following section. ALM
AL2.S AL2 function selection STD
AL3.S AL3 function selection STD
Note1: Nothing is displayed on Group display when each parameter is displayed.
Additional Contact Output
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
DO1.S DOn1 function selection STD
See the following section. DO
DO2.S DOn2 function selection STD
DO3.S DOn3 function selection STD
DO4.S DOn4 function selection STD
DO5.S DOn5 function selection STD
Note1: When each parameter is displayed, the terminal area (E1 to E4) is displayed on Group
display according to the suffix code and optional suffix code. “n” denotes the position of the
terminal area. (n = 1 to 4)
ContactOutputforControl
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
OR.S
OUT relay function
selection
STD
See the following section. ALM
OR2.S
OUT2 relay function
selection
STD
Note1: Nothing is displayed on Group display when each parameter is displayed.
Note2: OR.S and OR2.S can be used as status output when they are not used as control output.
OR2.S can be used for Heating/cooling type.
