1-4

IM 05P02D41-01EN

1.3 Control Functions

PID Control

PID control is a general control using the PID control-related parameters.

► 8.2.1PIDControl

Alarms

Retransmission

output

Electric

furnace

UP35A/UP32A

4-20 mA DC

Thyristor

SCR

Recorder

Heating/cooling Control

Heating/cooling control is available only for Heating/cooling type.

In Heating/cooling control, the controller outputs the result of control computation after

splitting it into heating-purpose and cooling-purpose signals.

► 8.2.3Heating/coolingControl

UP35A/UP32A

Cooling (relay signal)

Heating

(4-20 mA DC signal)

Heating unit

Cooling

water

Thyristor

SCR
