YOKOGAWA UP35A - List of Display Symbols

3-7
IM 05P02D41-01EN
Part Names
3
3.3 ListofDisplaySymbols
The following shows the parameter symbols, menu symbols, alphanumeric of guide, and
symbols which are displayed on the UP35A/UP32A.
Figure(commontoalldisplayarea)
0 1 2 3 4 5 6 7 8 9
PVdisplay(14segments):Alphabet
A B C D E F
G H I J K L
M N O P Q R
S T U V W X
Y Z
SymboldisplayandDatadisplay(11segments):Alphabet
c
(lower-case)
A B C D E F
G H I J K L
M N O P Q R
S T U V W X
Y Z
