YOKOGAWA UP35A User Manual

9-17
IM 05P02D41-01EN
Program Pattern Functions
9
SettingDetails
Parameter
symbol
Name
Display
level
Settingrange Menusymbol
JC Junction code STD
CONT: Switching for continuation
HOLD: Hold-on switching (the
controller holds the end-of-
segment setpoint when the
segment is completed, to perform
control).
LOC: Local-mode switching (the
controller switches to a local
setpoint when the segment is
completed).
W.SW: Wait during switching between
segments.
W.IV: Wait within a segment interval.
W.SL: Segment switching (the
controller switches to a local
setpoint when the segment is
completed after release.)
PLK.1 to PLK.2 (PLK.4 when the
option “/AP”isspecied.): Linked
to patterns 1 to 2 (4.)
INS.: Allows a segment to be added
totheendofaspeciedsegment.
DEL.:Allowsaspeciedsegmentto
be deleted.
PROG
WT.SW1
Wait function
ON/OFF
STD
OFF: Disable
ON: Enable
WT.UP1
Upper-side wait
zone
STD
0.0 to 10.0% of PV input range (EU)
WT.LO1
Lower-side wait
zone
STD
WT.TM1 Wait time STD
OFF: No function
0.00 to 999.59 (“hour.minute” or
“minute.second”)
* Available only for the wait time at
the segment switching.
* Use the parameter TMU to set
the time unit. (Common in the
instrument.)
TMU
Program time
unit
EASY
HH.MM: hour.minute
MM.SS: minute.second
CTL
The table below shows which JC parameter settings correspond to which set of the wait
zoneparameter(WZ.UP1, WZ.LO1) and wait time parameter (WT.TM1.)
SettingvalueofJC
W.SW
WT.TM1
WZ.UP1
WZ.LO1
SettingvalueofJC
W.IV
WZ.UP1
WZ.LO1
9.4SettingtheWaitFunctions
