9-14

IM 05P02D41-01EN

(2)WhenLSPandSSParedifferent

Seg.1 Seg.2 Seg.3

TSP

SSP

TSP

Local target

setpoint (LSP) in

Local operation

Seg.: Segment

Program pattern

Program operation start (LOC → PRG)

Time

Setpoint

SettingDetails

Parameter

symbol

Name

Display

level

Settingrange Menusymbol

SSP

Starting target

setpoint

EASY

0.0 to 100.0% of PV input range

(EU)

(Setting range: P.RL to P.RH)

PROG

STC Start code EASY

SSP: Program operation begins

with the starting target setpoint.

RAMP:Ramp-prioritizedPVstart

TIME:Time-prioritizedPVstart

LSP: Local-mode start

LSP

Local target

setpoint

EASY

0.0 to 100.0% of PV input range

(EU)

(Setting range: P.RL to P.RH)

LOC

9.3SettingtheProgramStartingConditions(STC)
