Program Pattern Functions

The following shows an example of linking the program patterns 2 and 4 (pattern-link).

However,thestartcode(STC)issettoRAMP(Ramp-prioritizedPVstarat.)

Setpoint

TimeTime

2 3 4 5 6

Pattern-link

Pattern 2

Segment 1 Segment 1

Pattern 2 Pattern 4

Time

Pattern 4

When ramp-prioritized PV start is selected, the start code (STC) setting for pattern 4 becomes enabled

at the time when pattern 4 starts.

JC of segment 6 = PLK.4

9.6OperationwithLinkedProgramPatterns
