9-43

IM 05P02D41-01EN

Program Pattern Functions

SettingDetails

Parameter

symbol

Name

Display

level

Settingrange Menusymbol

WAIT

Wait ON/OFF

switch

STD

Set an I relay number of contact

input.

Set “OFF” to disable the function.

Standard terminals

DI1: 5025, DI2: 5026,

DI3: 5027

E1-terminal area

DI11: 5041, DI12: 5042,

DI13: 5043, DI14: 5044,

DI15: 5045

E4-terminal area

DI41: 5089, DI42: 5090,

DI43: 5091, DI44: 5092,

DI45: 5093

DI.SL

AL1.S

AL1 function

selection

STD

Controlagforsegmenttransition:

4261

ALM

AL2.S

AL2 function

selection

AL3.S

AL3 function

selection

OR.S

OUT relay function

selection

OR2.S

OUT2 relay function

selection

DO1.S

DOn1 function

selection

STD

Controlagforsegmenttransition:

4261

DO2.S

DOn2 function

selection

DO3.S

DOn3 function

selection

DO4.S

DOn4 function

selection

DO5.S

DOn5 function

selection

n: Terminal area number (1 or 4)
