Output (Control and Retransmission) Functions

SettingDetails

Parameter

symbol

Name

Display

level

Settingrange Menusymbol

HYS

Hysteresis (in ON/OFF

control, or Position

proportional control)

Heating-side ON/OFF

control hysteresis

(in Heating/cooling

control)

EASY

In ON/OFF control: 0.0 to

100.0% of PV input range

span (EUS)

In Heating/cooling control

or Position proportional

control: 0.0 to 100.0%

PID

HY.UP

Upper-side hysteresis

(in ON/OFF control)

EASY

0.0 to 100.0% of PV input

range span (EUS)

HY.LO

Lower-side hysteresis

(in ON/OFF control)

EASY

Note1: The PID number (1 to 8, R) is displayed on Group display while each parameter is displayed.
