10-14

IM 05P02D41-01EN

SettingDetails

Parameter

symbol

Name

Display

level

Settingrange Menusymbol

HYS

Hysteresis (in ON/OFF

control, or Position

proportional control)

Heating-side ON/OFF

control hysteresis

(in Heating/cooling

control)

EASY

In ON/OFF control: 0.0 to

100.0% of PV input range

span (EUS)

In Heating/cooling control

or Position proportional

control: 0.0 to 100.0%

PID

HYSc

Cooling-side ON/OFF

control hysteresis

EASY 0.0 to 100.0%

Output dead band (in

Heating/cooling control

or Position proportional

control)

EASY

In Heating/cooling control:

-100.0 to 50.0%

In Position proportional

control: 1.0 to 10.0%

Note1: The PID number (1 to 4, or R) is displayed on Group display while each parameter is

displayed.
